CBB80 Lamp Compensation Capaitor

CBB80 Lamp Compensation Capaitor

Product Features:

With inner discharge resistance and overheating, this overcurrent protection device, product is safe and reliable.
Product with small volume, lightweight, high insulation resistance, high withstand voltage, low dissipation factor. good self-healing, stable performance.

Product Application:

Applicable to start and compensation of high-pressure sodium lamp, mercury board, improve the power factor.

  • CBB80 Lamp Compensation Capaitor
  • CBB80 Lamp Compensation Capaitor
PREV：No previous article
NEXT：No next article
Parameter
Technical parameter Reference value
Voltage range 250Vac ~ 660Vac，50/60Hz
Capacitance range 2μF～100μF
Capacitance tolerance ±3%,±5%
Operating temperature range -40℃~110℃
Withstand voltage T-T 2Un/60s
T-C 2Un+1000Vac/60s
Dissipation factor ≤0.004, 100Hz
Altitude ≤2000m
Reference standard GB/T18489, GB/18504，UL810,IEC/EN61048,IEC/EN61049

Capacitance 250-370AC 350-450AC
Plastic case Aluminum shell Plastic case Aluminum shell
Capacitance
6 34*65 30*60 34*65 30*70
8 34*65 30*70 34*75 34*65
10 34*65 34*70 34*75 34*75
12 34*65 34*70 34*75 40*70
16 42*65 40*70 42*75 42*80
18 42*65 40*70 42*75 42*80
20 42*75 42*80 45*75 50*75
25 42*75 42*82 50*75 50*75
30 45*75 45*90 50*75 50*75
32 50*75 45*90 50*75 50*75
35 50*75 50*100 50*100 50*100
50 50*90 50*100  55*100 50*100
60 50*100 50*100  55*120 55*125
70 50*120 55*100  55*130 55*135
80 55*125 55*125 60*130 60*125
90 55*125 55*125 60* 130 65*125
100 55*125 55*135 60*130 65*135
